- Commodity name: Fiber Optic Taper
- Commodity ID: HS-003
Product description: Optical image information transmission, which can enlarge or reduce the image. The image is close to one end of the fiber optic cone, and is decomposed into corresponding pixels by the tens of millions of fibers that make up the fiber optic cone; the regularly arranged fibers transmit the pixel information carried to the fiber optic cone one by one. the other end of the cone;
① The small end is coupled with the CCD, used in the low-light camera tube;
② In the new fingerprint identification device, it is used as the image transmission element between the fingerprint and the CCD;
③ The large end is coated with scintillator luminescent material, and the small end is coupled with CCD for imaging detection of non-visible light and high-energy rays.
Such as X-ray camera, radiation imaging detector, etc. The product is used in the field of medical imaging technology, molecular biology,
Such as biological information research of living small animals, gamma ray camera, X-ray tomography, positron tomography and other devices
Has a wide range of applications.Key words:- small
- used
- imaging
-
1. Wire diameter: 6μm, 4μm insertion and absorption filament;
2. Numerical aperture: >0.65;
3. Expansion coefficient: (87±2)×10-7/℃ in the temperature range of 20-450℃
4. Vacuum airtight Properties: Leak rate≦2.026×10-12 Pa.m3.s-1.
5. Collimated transmittance: > 65%.
6. Diffuse transmittance: ＞58%
7. Shear: ≤30μm;
8. Snake: ≤2% (effective area);
9. Barrel shape: ≤3.0% (effective area);
10. Pincushion: ≤ 3.0% (effective area);
